Appropriate for all positions on multi-purpose regional service vehicles.
Five-rib design enhances stability; multi-blade design improves traction and heat dissipation.
Grooved bottom protectors reduce stone drilling and extend tire life.
Wide tread design with specialized compounds lengthens driving range.
| WHEEL DIAMETER | SIZE | L.S | PARTS NUMBER | MAX PSI | SINGLE TIRE MAX LOAD LBS | DUAL TIRE MAX LOAD LBS | MEASURING RIM | APPROVED RIM WIDTH | OD INCH | SW INCH | TD 32ND | SIDEWALL |
| 22.5" | 255/70R22.5 | 16PR 140/137M | PDTBR97 | 120 | 5510 | 5070 | 7.50 | 6.75,7.50,8.25 | 36.61 | 10.04 | 16.9 | BLK |
| 315/80R22.5 | 20PR 157/154L | PDTBR107 | 130 | 9090 | 8270 | 9.00 | 9.00,9.75 | 42.36 | 12.28 | 18.7 | BLK |
*Every effort has been made to verify the accuracy of the listed Information.
Transamerica Tire cannot be held responsible for any discrepancies,and as such the information should be considered as approximate.
-
-
